Polypropylene Biaxial Geogrid
Ua los ntawm polypropylene
Siab tensile zog thiab modulus
Yooj yim rau tsim
Extending kev pab cuam lub neej ntawm pavement
Sub-qib Stabilization
Khoom Taw qhia
PP Biaxial Geogrids
MTTVS®Biaxial Geogrids yog tsim los ntawm polypropylene. Nws yog tsim los ntawm cov txheej txheem ntawm extruding, xuas nrig ntaus, cua sov, longitudinal stretching thiab transverse stretching. Cov khoom muaj zog tensile zoo nyob rau hauv ob qho tib si longitudinal thiab transverse cov lus qhia. Cov qauv no tseem tuaj yeem muab qhov zoo tshaj plaws rau kev kaw lub kaw lus rau kev siv zog ntau dua thiab muaj kev sib kis hauv cov av, uas yog tsim rau thaj chaw loj-tsheb thauj mus los-cov kabmob Reinforcement ntawm lub hauv paus. MTTVS®Biaxial Geogrids muab cov kev daws teeb meem yooj yim, nqi zoo rau cov av reinforcement.MTTVS®Biaxial Geogrids tau siv los ua kom muaj kev ruaj ntseg hauv av hauv ntau tshaj li peb puas txhiab txoj haujlwm thoob ntiaj teb, suav nrog txoj kev, txhawb nqa lub hauv paus thiab cov chaw ua haujlwm. MTTVS®Biaxial Geogrids tsim thiab sim ua kom tau raws li lossis dhau cov qauv kev lag luam thiab tau ua tiav siv rau ntau tshaj 10 xyoo.
Feature
● Siab tensile zog thiab modulus,
● Zoo heev tiv thaiv kev puas tsuaj
● Zoo heev tiv thaiv tshuaj tua kab mob
● Zoo heev tiv thaiv ib puag ncig raug.
● Txhim kho cov kabmob muaj peev xwm ntawm lub hauv paus
● Yooj yim rau kev tsim, txo tus nqi thiab tswj kev siv nyiaj
● Extending kev pab cuam lub neej ntawm pavement
Daim ntawv thov
● Base Stabilization
● Sub-qib Stabilization
● Kev txhim kho txoj kab nqes
● embankment stabilization
● Kev txhawb nqa av
● Kev txhim kho kev loj
● Lub hauv paus txhim kho qhov chaw nres tsheb loj
● Kev txhawb nqa cov mines thiab qhov av
PP Biaxial Geogrids SA Specifications:
Khoom | Txoj Kev Xeem | Chav tsev | GG1515 | GG2020 (L) | GG2525 | GG3030 (L) | gv4040 | wb 4545 | GG5050 | |||||||
MD | TD | MD | TD | MD | TD | MD | TD | MD | TD | MD | TD | MD | TD | |||
Polymer | - | - | PP | |||||||||||||
Minimun Carbon Dub | ASTM D 4218 (Tshooj 1) | % | 2 | |||||||||||||
Qhov kawg Tensile Strength | ASTM D 6637 Kev txiav txim siab | lbs/ft (kN/m) | 15 | 15 | 20 | 20 | 25 | 25 | 30 | 30 | 40 | 40 | 45 | 45 | 50 | 50 |
Tensile Strength @ 2% Lim | ASTM D 6637 Kev txiav txim siab | lbs/ft (kN/m) | 5 | 5 | 7 | 7 | 9 | 9 | 10.5 | 10.5 | 14 | 14 | 16 | 16 | 17.5 | 17.5 |
Tensile Strength @ 5% Lim | ASTM D 6637 Kev txiav txim siab | lbs/ft (kN/m) | 7 | 7 | 14 | 14 | 17 | 17 | 21 | 21 | 28 | 28 | 32 | 32 | 35 | 35 |
Strain@Ultimate Strength | ASTM D 6637 Kev txiav txim siab | % | 13 | |||||||||||||
Kev sib tshuam Efficiency | GRI GG 2 | % | 95 | |||||||||||||
Flexural Rigidity | ASTM D 7748 (Tshooj 7748) | mg cm | 69000 | 1090000 | - | 3930000 | 11480000 | - | - | |||||||
Aperture Stability | COJ Method | mN/deg | 0.64 | 0.7 | - | 1.43 | 2.1 | - | - | |||||||
ROLL DEMENSIONS | ||||||||||||||||
Yob Dav | - | ft (m) | 12.95(3.95) / 16.24(4.95) / 19.52(5.95) | |||||||||||||
Roll Length | Yam tsawg kawg nkaus | ft (m) | 164.04(50) | |||||||||||||
Roll Weight | - | kg | 39 | 48 | 58 | 68 | 96 | 110 | 128 | |||||||
Nco tseg:
MD: qhia txog Machine Direction
TD: txhais lus Transverse Direction
Custom Length xaj tuaj yeem haum.
